with Custom All-Terrain Package
hybrid-wheel drive power wheelchairs Custom All-Terrain Package
Next-level outdoor performance. No compromise indoors.
No Compromise! – The award-winning Alltrack R3 Outdoor is engineered for users who require tight quarters maneuverability but need a chair to handle challenging rural and/or urban environments. With its one of a kind HWD footprint, extra-wide tires, larger casters and advanced suspension, it delivers unstoppable traction and control over uneven, unpredictable terrain. Whether it’s dirt paths, gravel roads, or snowy trails, this powerhouse keeps you moving forward with confidence. Despite its off-road capabilities, the R3 Outdoor still delivers the compact agility needed indoors – making it the ultimate all-terrain companion for everyday adventurers.
HIGHLIGHTS
- Outdoor-ready Hybrid-Wheel Drive Technology for all-terrain performance and indoor maneuverability
- Award-winning, rugged design tested by real users in real environments
- Powerful 4-pole motors deliver speeds up to 8.5 mph
- 9” front and rear casters offer excellent grip and enhanced ride comfort
- Can be ordered with standard 14” drive wheels or sider, 14”x4” drive wheels for added comfort and grip on loose, soft terrain
- Optional flared front-end for enhanced caster clearance and added stability
- Available with Center Mount Elevating & Articulating Foot Platform
- NEW color and hydrographic finishes to match your style
COLORS
Alltrack R3 - Onyx Black Matte
Alltrack R3 - Indigo Blue
Alltrack R3 - Cobalt Blue
Alltrack R3 - Sublime
Alltrack R3 - Habanero Metallic
Alltrack R3 - Bubble Gum Metallic
Alltrack R3 - Candy Red
Alltrack R3 - Cabernet
TECHNICAL SPECIFICATIONS
| Configuration | Hybrid-wheel drive – Standard & HD (Alltrack R3 & R3-HD Hybrid with All-Terrain Package) |
| Suspension system | Patented Dual-Action Suspension: Fully independent 6-wheel interactive suspension with vertical shock absorption |
| Ground clearance1 | 3.5” (90 mm) with 14” (355 mm) drive wheels |
| Base width2 | 23.375” (595 mm) with GP 22 batteries or 25.375” (645 mm) with GP 24 batteries |
| Base length2 | 40.9″ (1040 mm) |
| Base turning radius | 21.75” (550 mm) |
| Weight capacity | Standard: 0-300 lb (0-136 kg) HD: 0-400 lb (0-180 kg) |
| 4-Pole motor options | 6.5 mph (10 km/h) |
| Transit option | 4-point tie-down attachment points compliant with ISO 7176-19 |
| Battery types | Two 12 V, deep cycle Gel cell Group 22NF (50 Ah) or Group 24 (70 Ah) |
| Battery charger | 8 A, off board |
| Electronics | Rnet (expandable 120 A) |
| Assistive driving package | Available with Smart-Track technology |
| Specialty controls | Compatible with Mo-Vis, ASL, Switch-It and Stealth as well as other current systems |
| Seat width range | Adjustable from 14” to 26” (355 mm to 660 mm) wide |
| Power seating option and HCPCS codes³ | Standard or HD weight capacity for Power Tilt, Power Recline with Mechanical Shear Reduction (MSR), Combination Power Tilt and Recline with MSR, Center Mount Elevating & Articulating Foot Platform, Independent Power Elevating & Articulating Legrests, Alta Power Seat Elevation |
| Seat to floor height range (With power tilt or Alta Power Seat Elevation) | 15.5” to 19.5” (395 mm to 495 mm) |
| Seat to floor height range (With power tilt and Alta Power Seat Elevation) | 17.5″, 18.5” or 19.5” (445 mm, 470 mm or 495 mm) |
| Seat to floor height range (With combo power tilt and seat elevate) | 15.5” to 19.5” (395 mm to 495 mm) |
| Seat to floor height range (With power tilt or Alta Power Seat Elevation) | 17” to 20″ (430 mm to 510 mm) |
| Seat to floor height range (With combo power tilt and seat elevate)* | 18.5” or 19.5” (470 mm or 495 mm) |
| Component weights4 | Compact base width 23.375”: 127 lb (57 kg) Batteries: Group 22NF: 2 x 36.6 lb (16.6 kg) Standard base width 25.375”: 132 lb (59 kg) |
| Drive wheel diameter | 14” (320 mm or 355 mm) |
| Caster wheel diameter | 9” (205 mm or 230 mm) |
1. Subject to variances depending on configuration and manufacturing tolerances.
2. Dimensions listed are for power base only.
3. Custom specialized power seating options available.
4. Contact Customer Service for additional weight information.
