MID-WHEEL DRIVE POWER WHEELCHAIRS
MAKE IT YOUR LIFESTYLE!
WHEN YOU NEED
RELIABILITY AND DURABILITY,
THE ALLTRACK M3 SERIES
NEVER DISAPPOINTS.
The Alltrack M3 Power Wheelchair provides the perfect blend of indoor maneuverability and outdoor performance, ideal for active lifestyles. Thanks to the patented dual-action suspension, the Alltrack M3 Power Wheelchair enables users to easily navigate everyday obstacles both indoors and out. Each Alltrack M3 Power Wheelchair is fully modular and can be equipped with a wide array of positioning and electronic accessories providing exceptional performance and endless possibilities.
21" NARROW OPTIONS
HIGHLIGHTS
- 21” Base width with 14” drive wheels – 2.375” narrower than full-size M3 & P3 with GP22 batteries
- Patented dual-action suspension – Same performance and function as full-size M3 & P3
- Full Tilt (50⁰) and/or Recline (160⁰) is available with 11’’ Alta Power Seat Elevation module
- Available with both Independent Elevating Legrests & Power Center Mount Foot Platform
- Compatible with VR2 (non-expandable) & R-net (expandable) electronics
- Available on Alltrack M3 and P3
- No additional cost, simple line-item choice on M3 & P3 order forms
- Seat to floor height as low as 15.5”
- Standard 4-pole, 6.5 mph motors
- Seat sizes up to 22” x 22”
- 14” or 12.5” drive wheels
- Group 22 batteries
24" NARROW OPTIONS
HIGHLIGHTS
- 24” Base Width with 14” drive wheels – 1.375” narrower than full-size M3 & P3
with GP24 batteries - Patented dual-action suspension – Same performance and function as full-size M3 & P3
- Available with both Independent Elevating Legrests and Power Center Mount Foot Platform
- Compatible with VR2 (non-expandable) & R-net (expandable) electronics
- Full Tilt (50⁰) and/or Recline (160⁰) is available with 11’’ Alta Power Seat Elevation module
- Available on Alltrack M3 & P3
- No additional cost, simple line-item choice on M3 & P3 order forms
- Group 24 batteries for maximum range
- Seat sizes up to 24” x 22”
- 14” or 12.5” drive wheels
- Seat to floor height as low as 15.5”
- Standard 4-pole, 6.5 mph motors
HIGHLIGHTS
- Patented Dual-Action Suspension: Fully independent 6-wheel interactive suspension with vertical shock absorption
- Compact turning radius
- Completely modular
- Full selection of power positioning options
- Seat to floor height as low as 15.5” (395 mm)
- Proven, 4-pole German motors
- Multiple frame, drive wheel and caster options
- Available in standard (300 lb weight capacity) and HD (450 lb weight capacity) models
COLORS
Alltrack M3 - Onyx Black Matte
Alltrack M3 - Indigo Blue
Alltrack M3 - Cobalt Blue
Alltrack M3 - Sublime
Alltrack M3 - Habanero Metallic
Alltrack M3 - Bubble Gum Metallic
Alltrack M3 - Candy Red
Alltrack M3 - Cabernet
TECHNICAL SPECIFICATIONS
| Configuration | Mid-wheel drive – Standard (Alltrack M3) or Heavy-duty (Alltrack M3-HD) |
| HCPCS Codes | K0848/K0856/K0861 – 0-300 lb Alltrack M3 K0850/K0858/K0862 – 0-450 lb Alltrack M3-HD |
| Suspension system | Patented Dual-Action Suspension: Fully independent 6-wheel interactive suspension with vertical shock absorption |
| Ground clearance1 | 3.5” (90 mm) with a 14” (355 mm) drive wheel, 2.875” (75 mm) with a 12.5” (320 mm) drive wheel |
| Base width2 | N2221 21″ (535 mm) with GP 22 batteries Standard 23.375″ (595 mm) with GP 22 batteries N2424 24″ (610 mm) with GP 24 batteries Standard 25.375″ (645 mm) with GP 24 batteries |
| Base length2 | 35.125” (890 mm) |
| Base turning radius | 20” (510 mm) |
| Weight capacity | 0-300 lb (0-136 kg) M3 0-450 lb (136-205 kg) M3-HD 400 lb (181 kg) for elevating seat on M3-HD |
| 4-Pole motor options | 6.5 mph (10 km/h) Std (M3 and M3-HD) 5.4 mph (8.7 km/h) option (M3-HD) |
| Transit option (Unoccupied) | 4-point tie-down brackets (Standard) |
| Transport option WC-19 (Occupied) |
Optional with select seat sizes and seating configurations (Not available with N2221 and N2424 options) |
| Battery types | Two 12 V, deep cycle Gel cell Group 22NF (50 Ah) or Group 24 (70 Ah) |
| Battery charger | 8 A, off board |
| Electronics | PG Drives VR2 (non-expandable 90 A) or R-net (expandable 90 A or 120 A) |
| Assistive driving package | Available with Smart-Track technology (Not available with the N2221 option) |
| Specialty controls | Compatible with Switch-It, Stealth, ASL or MO-VIS as well as other current systems |
| Seat width range | Adjustable from 15” to 26” (380 mm to 660 mm) wide (widths of 23″ to 26″ not available with the N2221 option) |
| Power seating options and HCPCS codes³ |
Power Tilt (E1002), Power Recline with Mechanical Shear Reduction (MSR) (E1004), Combination Power Tilt and Recline with MSR (E1007), Center Mount Elevating & Articulating Foot Platform (E1012), Independent Power Elevating & Articulating Legrests (E1010), Alta Power Seat Elevation (E2300) |
| Seat to floor height range (With power tilt or Alta Power Seat Elevation)* |
15.5” to 18.75” (395 mm to 475 mm) |
| Seat to floor height range (With combo power tilt and Alta Power Seat Elevation)* |
17.5” or 18.25” (445 mm or 465 mm) |
| Component weights4 | N2221 base width 21″: 126 lb (57 kg) Compact base width 23.375″: 128 lb (58 kg) N2424 base width 24″: 137 lb (62 kg) Standard base width 25.375″: 133 lb (60 kg) Batteries: Group 22NF: 2 x 36.6 lb (16.6 kg) Group 24: 2 x 54 lb (24.5 kg) |
| Drive wheel diameter | 12.5” or 14” (320 mm and 355 mm) |
| Caster wheel diameter | 6” or 8” (150 mm or 205 mm) |
* Add 1.5” (40 mm) when using the HD Alta Power Seat Elevation.
1. Subject to variances depending on configuration and manufacturing tolerances.
2. Dimensions listed are for power base only.
3. Custom specialized power seating options available.
4. Contact Customer Service for additional weight information.
